YXP160
Compact Thermal Module 160×120 VOx with Autofocus
1 / 3
Product Description
The YXP160 is an ultra-compact thermal imaging module featuring 160×120 resolution VOx microbolometer with ≤40mK thermal sensitivity. With autofocus capability and 0.3m-3m adjustable measurement distance, it delivers versatile thermal imaging in an incredibly small form factor.
Advanced features include point/line/area temperature modes, 15 color palettes, high/low tracking with on-screen and voice alerts, and thermal/blended image modes. Supports Android mobile systems via Type-C USB interface.
The ultra-compact design measures only 35.3×26×19.8mm and weighs just 17g with power consumption ≤0.41W. Perfect for smartphone integration and portable thermal imaging applications. Certified with FCC, RoHS, and CE standards.
Main Features
Ultra Compact
35.3×26×19.8mm, Only 17g
Autofocus
0.3m-3m Adjustable Distance
VOx Detector
160×120 Resolution, ≤40mK Sensitivity
15 Color Palettes
Thermal, Iron, Rainbow, Grayscale, etc.
Voice Alerts
On-screen and Voice High-Temp Alerts
Mobile Integration
Android Support via Type-C USB
Low Power
≤0.41W Power Consumption
Multi-language
Simplified/Traditional Chinese, English
Photo & Video
JPEG Image and MP4 Video Recording
Specifications
| Parameter | Value |
|---|---|
| Model | YXP160 |
| Temperature Range | -20°C~550°C |
| Infrared Resolution | 160×120 |
| Measurement Accuracy | ±2°C or ±2% of reading |
| Measurement Distance | 0.3m-3m adjustable |
| Detector Type | VOx microbolometer |
| Temperature Modes | Point, line, area |
| Emissivity | 0.01-1.00 (Default: 0.95) |
| Infrared Wavelength | 8~14μm |
| Pixel Size | 17μm |
| Spatial Resolution | 5.31mrad |
| Focal Length | 3.2mm |
| Frame Rate | 25Hz |
| Thermal Sensitivity | ≤40mK |
| Focus Type | Autofocus |
| Field of View | 50.0°(H)×37.2°(V), 63.6°(D) |
| Temperature Units | °C/°F |
| Temperature Display | Center, high, low (custom 3 pts, 3 lines, 3 areas) |
| Isotherms | Manual |
| High/Low Tracking | √ |
| High-Temp Alerts | On-screen and voice alerts |
| Color Palettes | 15 (thermal, iron, rainbow, grayscale, etc.) |
| Image Modes | Thermal, blended |
| Photo/Video Recording | √ |
| Image/Video Format | JPEG / MP4 |
| Interface | Type-C USB |
| Supported Languages | Simplified/Traditional Chinese, English |
| Mobile Systems | Android |
| Operating Temperature | -10°C~50°C |
| Humidity | 10%-90% RH (non-condensing) |
| Storage Temperature | -20°C~60°C |
| Power Consumption | ≤0.41W |
| Certifications | FCC, RoHS, CE |
| Product Dimensions | 35.3×26×19.8mm |
| Net Weight | 17g |
| Standard Accessories | Color box, storage bag, lens cleaning cloth, manual |
